175R5905753 /17 DPxK-19B/23B/P
2.8 - 5.5
Color gamut native red: x = 0.7; y = 0.3
native green: x = 0.2; y = 0.76
native blue: x = 0.145; y = 0.04
Power requirements 220V
Dimensions 604(H) x 754(W) x 1129(D) mm
23.78(H) x 29.69(W) x 44.45(D) inch
NB: min. 5 cm of air inlet spacing required at the bottom of projector
Weight 133 kg (293 lbs)
Ambient temperature 35°C / 95°F
Options ACS-2048
3D add-ons
Touch panel
Pedestal
A.6 Specifications of the DP4K-P
Overview
Digital MicroMirror Device™ 3 x 1.38” DC4K dark metal devices
Native resolution 4,096 x 2,160 pixels
Housing Hermetically sealed DMD and optical assembly
Lamp 2kW included (Xenon)
Up to 4kW possible
Compatible with models from all major brands
Light output 2,700 lumens (10% deviation possible)
Screen size Up to 5.5 m (18 ft)
Brightness uniformity 80% at sides, 75% at corners
Color uniformity Meets the DCI/SMPTE 431-1 specs
Native contrast ratio Target: 2,500:1
Min: 2,250:1
Color gamut native red: x = 0.7; y = 0.3
native green: x = 0.2; y = 0.76
native blue: x = 0.145; y = 0.04
Digital Video Inputs 4 x 3Gb/s HD-SDI inputs (max. two single-link HD-SDI, one dual-link HD-
SDI or one quad link 4K)
2 x DVI input
Control I/O Ethernet
8x GPIO
Serial RS232
Projector diagnostics Via Communicator postproduction software (included)
Via PC touch panel (optional)
