Barco DP2K-23B User Manual

187R5905753 /17 DPxK-19B/23B/P
General Purpose Input:
GPI 1-4
Definition
RJ-45 pin
EXT_GPIN_1_P 1
EXT_GPIN_1_N 2
EXT_GPIN_2_P 3
EXT_GPIN_2_N 4
EXT_GPIN_3_P 5
EXT_GPIN_3_N 6
EXT_GPIN_4_P 7
EXT_GPIN_4_N 8
GPI 5-8
Definition
RJ-45 pin
EXT_GPIN_5_P 1
EXT_GPIN_5_N 2
EXT_GPIN_6_P 3
EXT_GPIN_6_N 4
EXT_GPIN_7_P 5
EXT_GPIN_7_N 6
EXT_GPIN_8_P 7
EXT_GPIN_8_N 8
About 568A and 568B on an Ethernet connector RJ-45
TIA/EIA-568A and -568B are two standards for connecting Category 3 and Category 5 wire to connectors.
Both are appropriate for high speed data, though 568B is somewhat more common for installed wiring and
568A is more common in jumpers. There is no performance advantage either way. The only real difference
between the two is the order in which the pairs are used (orange and green).
Hold a cable as if to plug it into a wall jack, the locking tab down (contacts facing you). The contacts are
numbered 1-8 from left to right. Here's what you will see:
RJ-45 Pin Number
(Left >Right
copper side)
568A 568B AES -1-8
1 White/Green White/Orange AES 1&2 +plus
2 Green Orange AES 1&2
+minus
3 White/Orange White/Green AES 3&4 +plus
4 Blue Blue AES 5&6
+minus
5 White/Blue White/Blue AES 5&6 +plus
Pin configurations

Barco DP2K-23B Specifications

General

Contrast ratio (typical)	2000:1
Projector native resolution	2K (2048x1080)
Ethernet LAN	Yes
Ethernet LAN (RJ-45) ports	3
AC input voltage	200 - 240 V
Lamp power	4000 W

Weight and Dimensions

Depth	754 mm
Width	604 mm
Height	1129 mm
Weight	133000 g
