1. Safety
• Power connected to the X 8 tiles must meet the specifications outlined in the installation manual.
• Avoid any accidental bumping of the tile corners while installing or removing the X8 tiles. Since LED ’s of the X8 tiles are mounted
near by the edges of the LED boards, which is unavoidable in the design of a high resolution LED-wall, the corners of the X8
tiles become sensitive for mechanical damage. Be cause of that it is required to handle the X8 tiles with care at all times.
• X8 tiles w hich are not installed and w hich are not securely s tored in an X8 flight case, may only be placed vertically upon flat
surfaces free of clutter. M ake sure that the X 8 tile does not rest upon the bottom r ow of LED’s but upon the provide studs at
the bottom o f the rental frame.
• While removing or installing the X8 module always keep the LED side of the X8 tile parallel with the LED side of the remaining
neighboring X8 tiles. This to av oid any mechanical stress upon the corners of the X8 module.
• No force can be applied to the LED’s. Any LE D’s damaged due to mechanical stress are not covered by the warranty.
• Safety and functional features of the display cannot be defeated.
• It is not allowed to climb or hang any additional equipment on the back of an X8 w all. Nothing is to be allowed to hang from the
cables of an X8 tile.
• Any failures must be immediately and appropriately dea lt with (equipment returned to Barco). Failing equipment cannot be left
to run in a wall.
• No additional tools (hamm ers, pr y-bars, etc.) are to be used to force handles or locks into place. A ll moving parts should be
managed by hand.
• Only Barco cables sp ecified to be used with the X8 display are to be used to connect components in the X8 wall. Further, ca re
must be taken to connect signal on ly according to the installation m anual.
• X8 tiles are not to be used in the vicinity of any equipm ent tha t is not CE and UL/ETL certified.
• X8 tiles are not to be transported for any distance in containers other than Barco flight cases or Barco single uni
t pa ckaging.
Further, even the use of B arco flight cases or packaging material does not guarantee the X8 tiles a gainst damage due to
excessive force of impacts. All warranty claims regarding damaged X 8 tiles due to incorrect packing will be rendered invalid.
• X8 tiles are not to be co nnected to any non-Barco equipme nt (the X8 tiles are NOT HDMI compatible devices, despite the use
of HDMI-style connectors).
• When stacking X8 tiles, only Barco X8 feet can be used, and they must be leveled acc ording to the manual before installing X 8
tiles. Improper leveling can result in e xcessive forces on t he structural components of the X 8 tiles.
• When hanging X8 tiles, only Barco X 8 trusses can be us ed and they must be installed and connected according to the manual.
Improper hanging of X8 tiles can result in excessive forces on th e structural compon ents of the X8 tiles.
• When stacking or hanging X8 tiles, the guidelines outlined in the installation ma
nual must be followed to prevent movement
of the d isplay (including tipping). Further, X8 tiles ar e only to be installed vertically. Any tipping of a display will cause undue
stress on the structural com ponents of the X8 tiles, and could even allow the X8 wall to fall.
• When stacking X8 tiles, the X8 stacker must be used.
• When reconnecting com ponents in an X8 tile, care must be taken to ensure that cables are carefully routed according to the
installation manual to prevent damage to the cables or other pa rts of the X8 tile.
• Shaders can only be remove d using the approved shader removal tool and the me thod described in the X8 manual(s).
• X8 tiles can be cleaned only in accordance to the procedures defined in the X 8 manual(s).
• Ensure rigging hardware is able to handle the weight of the en tire X8 sy stem with appropriate safety factors.
• External rigging hardware must b e properly installed prior to hanging X8 tiles.
• Do not hang more than 13 X8 tiles (11 m) tall with the integral rigging hardware.
• Barco supplies a variety of stacking and hanging ac cessories for screens up to 3 tiles stacked or 13 tiles hanging.
1.5 Important warnings concerning flight cases
Important warnings concerning stack and transport X8 rental flight cases
• Maximum stack two (2) flight cases with X8 Rental Tiles high and three
(3) flight case with X 8 feet/truss acc essories high. Never
higher.
• Sur face on which flight cas e is standing must be level to ensure t hat the total load is evenly spread out among the four wheels.
The surface must also be able to support the load safely.
• Before stacking or transporting flight cases, check the wheels and their fixation screws for wear or defects.
• Before stacking or transporting flight c ases, check if the lock handles on eac h flight case are in good working order and locked
secure ly.
• When stacked, make sure the wheels of the upper flight case are precisely positioned in the stacking dishes of the flight case
below.
•Stackedflight cases m ay not be moved. Before stacking, the lower flight c ase must alrea dy be in its final resting position before
placing the second upon it.
• Never stack loaded flight cas es in a truck or other transport medium, unless each flight case is rigidly strapped tight.
• In the event of a wheel breaking, flight cases must be r igidly strapped tight to prevent a stack collapsing.
• Use an appropriate forklift to raise flight cases and take the necessary precautions to avoid pe rsonnel injury.
4
R5905164 X8 DISPLAY 07/11/2012
