SED SERIES WIRELESS SENSORS
Window Switch Door Switch
Door/window switch 8612-053
Wall mounted
motion sensor
8612-057
Ceiling mounted
motion sensor
8612-055
Model Selection
Wireless ZigBee Pro Motion Sensors
BrightStat controllers with ZigBee Pro wireless sensors
can be used in stand-alone mode, or with integration
to a central management system, to allow for advanced
functions such as central reservation and occupancy
functions.
Up to 10 different ZigBee motion sensors can be used
with a BrightStat room controller.
No tools are required for commissioning or servicing
the ZigBee devices. A simple interface on the devices
with an on-board LED and hidden switch provides all
required functions for local interaction. The controller
user interface has screens used to pair and configure
ZigBee devices (see below). Local information for
battery life and connectivity (heartbeat) are also
displayed through the ZigBee Pro wireless network.
