Manual 2100-680
Page 2 of 18
CONTENTS
Dimensions ........................................................ 3
Specifications .................................................... 3
Overview ............................................................ 4
Installation......................................................... 6
Remote Sensor Accessories ................................. 7
Home Screen Display .......................................... 8
How to Enter Setup Screen .................................. 9
Power Outage Clock Reset ................................. 10
Passive Infrared Sensor ..................................... 11
Optional Network Setup .................................... 15
Controllers' Occupancy Sequence
and Operation Schematic .................................. 16
SED Series Wireless Sensors .............................. 17
• If replacing an existing room controller, label wires before
removal of controller.
• Electronic controls are static sensitive devices. Discharge
yourself correctly before manipulating and installing room
controller.
• A short circuit or wrong wiring may permanently damage
controller or equipment.
• BrightStat controllers are designed for use as operating
controls only and are not safety devices. Tampering with the
devices or unintended application of the devices will result in
a void of warranty.
• This device must be installed to provide a separation
distance of at least 8" (20cm) from all persons and must not
be collocated or operating in conjunction with any other
antenna or transmitter.
!
