Bard WH423 - Tables; Wall Mount General Information; Heat Pump Wall Mount Model Nomenclature; Table 1 Electric Heat Table

Manual 2100-487
Page 4 of 23
WALL MOUNT GENERAL INFORMATION
HEAT PUMP WALL MOUNT MODEL NOMENCLATURE
WH 48 1 – A 10 X X X X X B
TABLE 1
ELECTRIC HEAT TABLE
sledoM
WK
A-324HW
B-324HW
B-384HW
C-324HW
A-384HW
A-406HW
B-384HW
B-406HW
C-384HW
C-406HW
1-0421-8023-0423-8023-0641-0421-8023-0423-8023-064
AUTBAUTBAUTBAUTBAUTBAUTBAUTBAUTBAUTBAUTB
4 7.61056314.4104201
58.02560711.81008218.02560711.8100821
64.41005025.21063512.708402
97.12006037.81030328.01007037.12006037.81030328.0100703
016.14031432.63006526.14031432.6300652
515.26002151.45004832.63002152.13004830.81002155.26002151.45004832.63002152.13004830.8100215
81 3.34004165.7305064
02 2.38052861.2700215
VENTILATION OPTIONS
X – Barometric Fresh Air Damper (Standard)
B – Blank-off Plate
M – Motorized Fresh Air Damper
V – Commercial Room Ventilator - Motorized
with Exhaust
E – Economizer (Internal) - Fully Modulating
with Exhaust
R – Energy Recovery Ventilator - Motorized
with Exhaust
COIL OPTIONS
X – Standard
1 – Phenolic Coated Evaporator
2 – Phenolic Coated Condenser
3 – Phenolic Coated Evaporator
and Condenser
CONTROL MODULES
(See Spec. Sheet S3210)
NOTE: For 0KW and circuit breakers (230/208V) or pull disconnects (460V) applications, insert 0Z in the KW field of model number.
MODEL
NUMBER
CAPACITY
42 – 3½ Ton
48 – 4 Ton
60 – 5 Ton
KW
00 – No KW
05 – 5 KW
06 – 6 KW
09 – 9 KW
10 – 10 KW
15 – 15 KW
18 – 18 KW
20 – 20 KW
FILTER OPTIONS
X – 1-Inch Throwaway (Standard)
W – 1-Inch Washable
P – 2-Inch Pleated
VOLTS & PHASE
A – 230/208/60-1
B – 230/208/60-3
C – 460/60-3
REVISION
COLOR OPTIONS
X – Beige (Standard)
1 –White
2 – Mesa Tan
4 – Buckeye Gray
OUTLET OPTIONS
X – Front (Standard)
