barfield 2311FA - SPECIFICATIONS

56-101-00212 Revision E Page | 5
3. SPECIFICATIONS
Note: The dimensions listed below exclude the Master Pressure Gauge connected at the
Adapter (refer to Figure 6, item #14). The range, accuracy, and type for the Master
Pressure Gauge (sold separately) depends on the requirements of the system(s) to
be tested and the user's preferences (refer to Table 4).
A. Physical Characteristics
Size (H, W, L)
9.8 in. (24.9 cm), 7.8 in. (19.8 cm), 7.5 in. (19.1 cm)
Weight
3.0 lbs. (1.36 kg)
Table 1 Physical Characteristics
B. Environmental
Operating Temp.
0°C to 40°C (32°F to 104°F)
Storage Temp.
-20°C to 60°C (-4°F to 140°F)
Operating Humidity
N/A
Pressure Connection
1/8 Female NPT
Pressure Gauge
Connection
1/4 Female NPT
Hydraulic Fluid
Reservoir capacity: 134 cm
3
(8.18 in
3
)
Table 2 Environmental
C. Conformity
Pressure Safety
Pressure Equipment Directive - Class: Sound Engineering
Practice (SEP)
Approved
Not CE Marked as per the Directive
Table 3 Conformity
