Barnes OGP 2 HP - Parts Kits and List

34
PARTS KITS
Seal Repair Kit ...........P/N: 116664 Item #’s: 6, 7, 13, 15, 20, 25, 33, 36, 38
Overhaul Kit .............. P/N: 116665 Item #’s: 3, 5, 6, 7, 9, 13, 15, 20, 25, 28, 29, 33, 36, 38
Cutter Kit ...................P/N: 116666 Item #’s: 5, 6, 7, 9, 13, 15, 36
PARTS LIST
ITEM QTY PART NO. DESCRITION
1 1 115321
115321A
Volute (L & AU)
Volute (CC, CE, CO, CT)
2 1 110331 Handle (AUE)
3 1 115322 Seal Plate
4 1 108342
110328
118256
Motor Housing (L)
Motor Housing (AUE)
Motor Housing (CC, CE, CO, CT)
5 1 082085B Shredding Ring
6 1 067556 Washer
7 1 070704 Skhd Screw, 1/4-20 x .75” SS
8 1 108369 † Discharge Flange 1-1/4” NPT
9 1 082088 Radial Cutter
10 1 115324 Impeller, Second Stage
11 1 625-01558 O-Ring (-223)
12 2 1-131-1 † Screw, 5/16-18 x 1.25” SS
13 2 067567 Square Ring
14 1 115323 Impeller, First Stage
15 14 026322 Lockwasher, 5/16” SS
16 A/R --------- LOCTITE™ RC609
17 A/R --------- LOCTITE 242
18 2 062941 † 5/16” Flatwasher
19 1 115325 Spacer Sleeve
20 1 110395SD Seal, Silicon-Carbide (STD)
21 1 115326 Suction Cover
22 A/R --------- Permatex Sealent 2C
24 90 oz 029034 Cooling Oil - Mtr. Housing
25 1 095368 Square Ring
26 1 036391 Capacitor, Run
27 1 099198 Capacitor, Start
28 1 116658 Ball Bearing, Upper (Not Shown)
29 1 116659 Ball Bearing, Lower
30 1 or 2 625-02117 Sleeve
31 1 115327 Motor, 2HP, 240 Volt, 1 Phase
32 1 103760 Terminal Block, Power, Manual
33 1 or 2 2-31051-224 O-Ring
34 1 or 2 105197 Retaining Ring
36 14 1-156-1 Screw, 5/16-18 x 1.00” SS
37 1 109498 12/3 Cord Set, 15Ft (STD)
37A 1 103582 Compression Flange
38 1 014270 Pipe Plug, C’sunk, 3/8” NPT
39 1 119104B Anti-Siphon Cover
ITEM QTY PART NO. DESCRITION
40 1 112422 Gasket
41 3 03121-B HXHD Screw 1/4-20 x .75” SS
42 1 105377B Anti-Siphon Cover Plate
* Models with ESPS Level Control
50 4 1-156-1 Screw, 5/16-18 x .1” SS
51 4 026322 Lockwasher, 5/16” SS
54 2 113287 Wiring Harness Assy
56 1 113274
EcoTRAN
Cord Set (AUE)
Cord Set (CE-See man.119061)
Cord Set (CC)
Cord Set (CT)
56A 1 103582♦ Compression Flange
57 1 113271 Terminal Block, Power
60 1 113272 Terminal Block, Level Control
(AU - series)
62 1 121676-M
119068
ESPS-150 Level Control
CE Only
63 4 2-23030-50 SkHd Screw 5/16-18 x 1.25”
Contact your local Distributor or the Factory for other cord lengths
and other optional equipment.
(*) Automatic - ESPS Level Control
(♦) Supplied with Item 56.
(†) L Series ONLY. NOT USED ON CC, CE, CO, CT
