SINGLE RAMP & DWELL CONTROLLER
Note
The program must be stopped and
the controller must be displaying the
actual temperature before beginning
the Setup.
Program Setup
1. Press the PAGE button until the “SP” is displayed.
2. Press the SCROLL button once, “SPrr” (Ramp Rate)
will be displayed, set the desired Ramp rate with the
UP or DOWN buttons, if the ramp to setpoint feature is
needed. If the Ramp rate is not needed, then set to
“OFF” with the UP or DOWN buttons.
3. Press the SCROLL button once, “tm.OP” (Ramp &
Dwell mode) will be displayed, select the desired
mode with the UP or DOWN buttons. (Opt. 1, Opt. 2,
Opt. 3, Opt. 4, Opt. 5)
4. Press the SCROLL button once, “dwEll” will be dis-
played, set the desired Dwell time with the UP or
DOWN buttons. (Dwell in minutes.)
5. Press the PAGE button until the Actual temperature is
displayed.
Running the Program
1. Press the SCROLL button until “StAt” is displayed, set
to “run” with the UP or DOWN buttons.
2. Press the PAGE button to display Actual temperature.
Stopping the Program
Press the SCROLL button until “StAt” is displayed, set to “oFF”
with the UP or DOWN buttons.
Clearing the Flashing End
Press the PAGE and SCROLL buttons at the same time.
