9
INTRODUCTION
Principles of Operation
1. Furnace: The furnace chamber is heated by four
electric resistance heaters which are embedded in a
refractory material. The chamber is insulated with a
ceramic fiber insulation. The temperature is con-
trolled by an automatic proportioning controller using
a platinel thermocouple to feed back information. The
control is located under the furnace chamber and is
well insulated from the heat generated in the furnace
chamber. The temperature is controlled by one of
three types of controllers.
MODEL NUMBER DIGITAL COMMUM. TOTAL NUMBER OF NUMBER OF
PROGRAMMABLE STORED
SEGMENTS PROGRAMS
F30420C-33-80 NO 8
F30420-33-60-80 NO 8
F30420C-60-80 NO 8
F30420C-80 NO 8
F30428C-60-80 NO 8
F30428C-80 NO 8
F30430CM YES 64 16 Segment Programs
F30430CM-33 YES 64 16 Segment Programs
F30430CM-33-60 YES 64 16 Segment Programs
F30430CM-60 YES 64 16 Segment Programs
F30438CM YES 64 16 Segment Programs
F30438CM-60 YES 64 16 Segment Programs
