8 SEGMENT & 4X16 SEGMENT PROGRAMMABLE MODELS W/OTP
PAGE button: allows you to choose a parameter from a
list of parameters.
SCROLL button: allows you to choose a parameter within
a list of parameters.
UP button: allows you to increase the value in the lower
display.
DOWN button: allows you to decrease the value in the
lower display.
Controller Parameters
Home Display
°C: measured temperature in Celsius. Temperature units
can not be changed without entering the configuration.
Contact Customer Service if a different temperature unit is
required.
OP: % output power demand; displayed in lower display
(cannot be changed).
C.id: Controller identification number.
PrG: Program number (displayed when a program is run-
ning; 4x16 programmable models only.)
IdHi: Deviation High Alarm
tunE: One-shot autotune enable.
run LiSt (Program Run List)
PrG: Currently running program (only used on 4x16 pro-
grammable models)
StAt: Displays the program status [OFF, run (running
active program), hoLd (program on hold), HbAc (waiting for
process to catch up), End (program completed)] in the
lower display. The controller will default to “OFF.”
FASt: Fast run through program (no/YES). The controller
will default to “no.”
SEG.d: Flash active segment type in the lower display of
the home display (no/YES). The controller will default to
“no.”
23
