29
8 SEGMENT & 4X16 SEGMENT PROGRAMMABLE MODELS W/OTP
bAnd (Deviation Band Holdback): combines the fea-
tures of the high and low deviation holdback in that it
holds the program back when the process variable
deviates above or below the setpoint by more than the
holdback value.
To set the holdback type:
1. Press the PAGE button until you reach the
program list (ProG LiSt).
2. Press the SCROLL button until display reads,
“Hb.”
3. Press the UP or DOWN button to toggle
between “bAnd, Hi, Lo and OFF.”
Hb U: Holdback Value
To set the holdback value:
1. Press the PAGE button until you reach the
program list (ProG LiSt).
2. Press the SCROLL button until display reads,
“Hb.U.”
3. Press the UP or DOWN button to enter a
holdback value.
rmP.U: Setting Ramp Units
Ramp units are time units which are used in “rmP.r”
segments (ramp to a setpoint at degrees per second,
minute or hour) and “rmP.t” segments (ramp to setpoint
in a specific amount of time). See “Setting the
Segment Type” for an explanation on how to set a
ramp segment.
1. Press the PAGE button until you reach the
program list (ProG LiSt).
2. Press the SCROLL button until display reads,
“rmP.U.”
3. Press the UP or DOWN button to toggle
between seconds, minutes and hours.
Note
The value set in this parameter is always
for the entire program.
