Specifications, Requirements, and Precautions
6 Basler ace GigE
Specification acA1600-20gm/gc acA2500-14gm/gc
Sensor Size
(H x V pixels)
gm: 1628 x 1236
gc: 1624 x 1234
gm: 2592 x 1944
gc: 2590 x 1942
Sensor Type Sony ICX274 AL/AQ
Progressive scan CCD
Global shutter
Aptina MT9P031
Progressive scan CMOS
Rolling shutter
Optical Size 1/1.8" 1/2.5"
Pixel Size 4.4 µm x 4.4 µm 2.2 µm x 2.2 µm
Max. Frame Rate
(at full resolution)
20 fps 14.6 fps
Mono/Color Mono or color (color models include a Bayer pattern RGB filter on the sensor)
Data Output Type Fast Ethernet (100 Mbit/s) or Gigabit Ethernet (1000 Mbit/s)
Pixel Data Formats Mono Models: Mono 8 YUV 4:2:2 Packed
Mono 12 YUV 4:2:2 (YUYV) Packed
Mono 12 Packed
Color Models: Mono 8 Bayer BG 12 Packed
Bayer BG 8 YUV 4:2:2 Packed
Bayer BG 12 YUV 4:2:2 (YUYV) Packed
ADC Bit Depth 12 bits
Synchronization Via external trigger signal, via the Ethernet connection, or free run
Exposure Control Via external trigger signal or programmable via the camera API
Camera Power
Requirements
PoE (Power over Ethernet 802.3af compliant)
or
+12 VDC (±10%), < 1% ripple, supplied via the camera’s 6-pin Hirose connector
~ 3.4 W when using Power over Ethernet
~ 2.9 W @ 12 VDC when supplied via
the camera’s 6-pin connector
~ 2.5 W when using Power over Ethernet
~ 2.2 W @ 12 VDC when supplied via
the camera’s 6-pin connector
I/O Ports 1 opto-isolated input line and 1 opto-isolated output line
Lens Adapter C-mount
Size (L x W x H) 42.0 mm x 29 mm x 29 mm (without lens adapter or connectors)
60.3 mm x 29 mm x 29 mm (with lens adapter and connectors)
Table 3: General Specifications
