9171100990 Rev R BE1-32R, BE1-32O/U General Information 1-7
Figure 1-11. Modified Type A Sensing
MODEL AND STYLE NUMBER
BE1-32R and -32 O/U Directional Power Relays electrical characteristics and operational features are
defined by a combination of letters and numbers that make up the style number. Model numbers BE1-
32R or BE1-32O/U designate the relay as a Basler Electric, Class 100, Directional Power Relay. The
model number and style number describe the options included in a specific device, and appear on the
front panel, draw-out cradle, and inside the case assembly. Upon receipt of a relay, be sure to check the
style number against the requisition and the packing list to ensure that they agree.
The style number chart is shown in Figure 1-12.
