9171100990 Rev R BE1-32R, BE1-32O/U General Information 1-13
Timing—continued
Accuracy
Instantaneous: <80 ms (60 Hz) or <100 ms, (50 Hz) up to a real power
magnitude of 2 times the setting
Definite: ±5 percent or 50 ms, whichever is greater
Inverse: +5 percent or 50 ms, whichever is greater
NOTE: Operating time is repeatable within 2% or 50 ms
(whichever is greater) for any combination of time dial and power
settings within the specified operating temperature range.
Power Range (Pickup)
The power pickup range is adjustable over the ranges listed in Table 1-4.
Table 1-4. Power Pickup Ranges
Switch Position (in watts)
Sensing
Input Type
Nom.
Volts
Range
A B C D E F G H J K
Hi 2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0 18.0 20.0 1
Lo 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0
Hi 20 40 60 80 100 120 140 160 180 200 2
Lo 5 10 15 20 25 30 35 40 45 50
Hi 100 200 300 400 500 600 700 800 900 1000
A, B or V
1-phase
120
3
Lo 25 50 75 100 125 150 175 200 225 250
Hi 6.0 12.0 18.0 24.0 30.0 36.0 42.0 48.0 54.0 60.0 1
Lo 1.5 3.0 4.5 6.0 7.5 9.0 10.5 12.0 13.5 15.0
Hi 60 120 180 240 300 360 420 480 540 600 2
Lo 15 30 45 60 75 90 105 120 135 150
Hi 300 600 900 1200 1500 1800 2100 2400 2700 3000
C, D, or E
3-phase
120
3
Lo 75 150 225 300 375 450 525 600 675 750
Hi 4.0 8.0 12.0 16.0 20.0 24.0 28.0 32.0 36.0 40.0 4, 7
Lo 1.0 2.0 3.0 4.0 5.0 6.0 7.0 8.0 9.0 10.0
Hi 40 80 120. 160 200 240 280 320 360 400 5, 8
Lo 10 20 30 40 50 60 70 80 90 100
Hi 200 400 600 800 1000 1200 1400 1600 1800 2000
A, B, or V
1-phase
208
or
240
6, 9
Lo 50 100 150 200 250 300 350 400 450 500
Hi 12.0 24.0 36.0 48.0 60.0 72.0 84.0 96.0 108.0 120.04, 7
Lo 3.0 6.0 9.0 12.0 15.0 18.0 21.0 24.0 27.0 30.0
Hi 120 240 360 480 600 720 840 960 1080 1200 5, 8
Lo 30 60 90 120 150 180 210 240 270 300
Hi 600 1200 1800 2400 3000 3600 4200 4800 5400 6000
C, D, or E
3-phase
208
or
240
6, 9
Lo 150 300 450 600 750 900 1050 1200 1350 1500
Type Tests
Dielectric Strength
Tested in accordance with IEC 60255-5 and IEEE C37.90. Withstands the following tests.
All circuits to ground: 2,121 Vdc
Input to output circuits: 1,500 Vac or 2121 Vdc
Surge Withstand Capability (SWC)
Qualified to IEEE C37.90.1-1989, Standard Surge Withstand Capability (SWC) Tests for Protective
Relays and Relay Systems
