9171100990 Rev R BE1-32R, BE1-32O/U General Information 1-9
SPECIFICATIONS
Current Sensing
BE1-32R and -32 O/U Directional Power Relays are designed for use with five amperes nominal (50/60
HZ) system current transformer secondaries. The input sensing current transformers within the relay are
rated as follows.
Sensing Input Ranges 1, 4, and 7 ∗
Continuous Rating: 7 A
1 Minute Rating: 10 A
1 Second Rating: 140 A
∗
Refer to Section 3, Functional Description, Current Sensing for sensing input range 1, 4, and 7 current
rating and burden considerations.
Sensing Input Ranges 2, 3, 5, 6, 8, and 9
Continuous Rating: 10 A
1 Minute Rating: 15 A
1 Second Rating: 200 A
Burden
Burden values (in ohms) are listed for each sensing input range in Table 1-2.
Table 1-2. Current Sensing Burden in Ohms
Sensing Input Range
1, 4, 7 ∗
2, 5, 8 3, 6, 9
Range
Low High Low High Low High
Tap A 4.811 0.400 0.096 0.022 0.013 0.010
Tap B 2.466 0.240 0.058 0.019 0.012 0.010
Tap C 1.677 0.190 0.045 0.018 0.011 0.010
Tap D 1.277 0.165 0.039 0.018 0.011 0.010
Tap E 1.036 0.151 0.034 0.017 0.011 0.010
Tap F 0.874 0.142 0.032 0.017 0.011 0.010
Tap G 0.760 0.134 0.030 0.017 0.011 0.010
Tap H 0.674 0.129 0.0029 0.017 0.011 0.010
Tap J 0.611 0.126 0.028 0.017 0.011 0.010
Tap K 0.556 0.123 0.027 0.017 0.011 0.010
∗
See Section 3, Functional Description, Current Sensing for sensing input range
1, 4, and 7 burden considerations.
Voltage Sensing
Voltage signals are provided by the secondary windings of standard potential transformers (100/200, 50
Hz or 120/240, 60 Hz).
Continuous Voltage Rating: 150% of nominal
Burden: <1 VA
Targets
Electronically latched, manually reset target indicators are optionally available to indicate that a trip output
contact has been energized. Either internally operated or current operated targets may be selected.
Internally operated targets should be selected if the relay has normally closed output contacts.
Current Operated Targets
Minimum Required Current: 200 mA
Continuous Rating: 3 A
2 Minute Rating: 7 A
1 Second Rating: 30 A
