9171100990 Rev R BE1-32R, BE1-32O/U Introduction i
INTRODUCTION
This instruction manual provides information about the operation and installation of the BE1-32R and
BE1-32O/U Directional Power Relays. To accomplish this, the following information is provided:
• General Information and Specifications
• Controls and Indicators
• Functional Description
• Installation
• Tests and Adjustments
WARNING!
To avoid personal injury or equipment damage, only qualified personnel should
perform the procedures in this manual.
NOTE
Be sure that the relay is hard-wired to earth ground with no smaller than 12 AWG
copper wire attached to the ground terminal on the rear of the unit case. When
the relay is configured in a system with other devices, it is recommended to use a
separate lead to the ground bus from each unit.
