Basler BE2000E - AVR Operating Mode; FCR (Manual) Operating Mode; Var Operating Mode; PF Operating Mode

68 9287500995 Rev B
AVR Operating Mode
Adjustment Range ...................... See generator voltage sensing
Voltage Regulation ..................... ±0.25% over load range at rated PF and constant generator frequency
Temperature Drift ....................... ±0.5% for a 40°C change
Response Time .......................... ≤ 1 cycle
Underfrequency (V/Hz)
Characteristic ............................. Slope from 1 to 3 PU is adjustable in 0.01 increments
Range ......................................... 40 to 65 Hz
Increment ................................... 0.01 Hz
FCR (Manual) Operating Mode
Adjustment Range ...................... 0 to 3 Adc
Increment ................................... 0.01 A
Var Operating Mode
Adjustment Range ...................... 100% to –100%
Increment ................................... 0.1%
PF Operating Mode
Adjustment Range ...................... 0.6 lead to 0.6 lag
Increment ................................... 0.001
Parallel Compensation
Modes ......................................... Reactive Droop and Reactive Differential (cross-current)*
Droop
Adjustment Range ...................... 0 to 10%
Increment ................................... 0.01%
* Burden can exceed 1 VA if external resistors are added to the CT circuit.
Communication Port
Interface ..................................... Full Duplex RS-232
Connection ................................. DB-9 connector on rear panel
Baud ........................................... 4800
Data Bits ..................................... 8
Parity .......................................... None
Stop Bit ....................................... 1
Field Overvoltage Protection
Pickup ......................................... 0 to 250 Vdc
Time Delay ................................. 15 seconds (fixed)
Field Overcurrent Protection
Pickup
Adjustment Range ...................... 0 to 7.5 Adc
Increment ................................... 0.001 Adc
Time Delay
Adjustment Range ...................... 0 to 10 seconds
Increment ................................... 1 second
Specifications BE2000E
