Technical Specifications
70 Basler IP Camera
Minimum PC
Requirements
Pentium 4, 2.4 GHz or higher, 256 MB RAM or more
AGP Graphics card, 64 MB RAM or more
1280 x 1024 display or better
100 Mbps NIC
Win 2k, XP, Vista, or Server 2003 OS
Internet Explorer 6.0 or higher
Power PoE (Power over Ethernet IEEE 802.3af) or + 7 to + 20 VDC
Power consumption is 5 W max at 12 VDC
Connectors Screwable RJ-45 connector for 10/100 Base-T Ethernet, full or half duplex
6-pin Phoenix terminal for DC power, digital I/O, and RS-232
IR-Cut Filter Fixed filter Automatically
removable filter
Fixed filter
Operating Conditions 0° to 50° C (32° to 122° F)
20% to 80% relative humidity (non condensing)
Standards FCC Class A/B, CE, RoHS
Housing 89.9 mm x 29 mm x 44 mm, full metal casing
Weight ~ 230 g
Specification BIP-1300c BIP-1300c-dn BIP-1600c
Table 5: BIP-1300c and BIP-1600c Technical Specifications
