Technical Specifications
Basler IP Camera 69
6.2 BIP-1300c and BIP-1600c Specifications
Specification BIP-1300c BIP-1300c-dn BIP-1600c
Sensor Sony ICX445
1/3" progressive scan color CCD
Sony ICX274
1/1.8" progressive scan color CCD
Effective Pixels 1280 (H) x 960 (V) 1600 (H) x 1200 (V)
Pixel Size 3.75 µm x 3.75 µm 4.4 µm x 4.4 µm
Frame Rate
Full resolution:
D1 (720 x 480):
MJPEG MPEG-4 H.264
13 fps 8 fps 4 fps
30 fps 30 fps 18 fps
(The max sensor readout rate is 30 fps.)
MJPEG MPEG-4 H.264
8 fps 5 fps 3 fps
30 fps 30 fps 18 fps
(The max sensor readout rate is 14 fps.)
Minimum Illumination 1.54 lux
(F1.0, 75 ms)
Color mode:
1.54 lux
(F1.0, 75 ms)
Mono mode:
0 Lux, IR sensitive
0.6 lux (F1.4, 30 ms)
Lens Mount CS-mount, DC Iris drive
Image Settings Automatic gain, exposure area, backlight compensation, white balance,
electronic shutter, 180° image rotation, electronic PTZ via AOI (API),
text overlay, privacy masks, motion detection
Resolutions From 64 x 40 to 1280 x 960 (free
scaling), 4:3, 16:9
Multiple Areas of Interest (AOIs)
From 64 x 40 to 1600 x 1200 (free
scaling), 4:3, 16:9
Multiple Areas of Interest (AOIs)
Video Compression Motion JPEG: Multiple compression Levels
MPEG-4: SP (Level 3), ASP (Level 5)
H.264 (MPEG-4 AVC): Baseline (Level 3)
Video Streaming Simultaneous dual encoding for MJPEG and MPEG-4 or H.264
Multi streaming for MJPEG
Multicast and unicast
VBR and CBR
Alarm Management Ring buffer for pre and post alarm
Events triggered by motion detection or external input
Image upload via FTP or Email
Protocols TCP/IP, HTTP, UDP, ICMP, ARP, DHCP, NTP,
RTP, RTSP, RTCP, SMTP, IGMP, UpnP
Processor / Memory 600 MHz dual core multimedia DSP, FPGA
128 MB RAM, 8 MB Flash
Battery backed-up real time clock
Table 5: BIP-1300c and BIP-1600c Technical Specifications
