Configuring the Camera
34 Basler IP Camera
3.6 Alarm Handling Parameters
The parameters in the Alarm Handling group are used to select the sources that can declare an
alarm condition and to control the actions that will be taken when an alarm condition is declared.
3.6.1 Alarm Sources Section
The alarm sources section of the alarm handling parameters group is used to select the sources
that can declare an alarm condition.
User Trigger Tab
Source Enable - Check the Source Enable box on the User Trigger
tab to enable the user trigger as a source for declaring an alarm
condition.
Digital Input Tab
Source Enable - Check the Source Enable box on the Digital Input
tab to enable the camera’s digital input line as a source for declaring
an alarm condition.
If the digital input line is enabled as an alarm source and the line
becomes active, an alarm condition will be declared.
Motion Detection Tab
Source Enable - Check the Source Enable box on the Motion
Detection tab to enable motion detection as a source for declaring an
alarm condition.
If motion detection is enabled as an alarm source and motion is
detected, an alarm condition will be declared. (See Section 3.5 on
page 32 for more information about motion detection.)
If the user trigger is enabled as an alarm source, you
can click the User Trigger button to declare an alarm
condition.
