6 Technical Specifications
6.1 BIP-640c and BIP1000c Specifications
Specification BIP-640c BIP-640c-dn BIP-1000c BIP-1000c-dn
Sensor Sony ICX424
1/3" progressive scan color CCD
Sony ICX204
1/3" progressive scan color CCD
Effective Pixels 640 (H) x 480 (V) 1024 (H) x 768 (V)
Pixel Size 7.4 µm x 7.4 µm 4.65 µm x 4.65 µm
Frame Rate
Full resolution:
D1 (720 x 480):
MJPEG MPEG-4 H.264
30 fps 30 fps 19 fps
30 fps 30 fps 18 fps
(The max sensor readout rate is 71 fps.)
MJPEG MPEG-4 H.264
20 fps 12 fps 7 fps
30 fps 30 fps 18 fps
(The max sensor readout rate is 30 fps.)
Minimum Illumination 0.98 lux
(F1.0, 30 ms)
Color mode:
0.98 lux
(F1.0, 30 ms)
Mono mode:
0 Lux, IR sensitive
1.3 lux
(F1.4, 30 ms)
Color mode:
1.3 lux
(F1.4, 30 ms)
Mono mode:
0 Lux, IR sensitive
Lens Mount CS-mount, DC Iris drive
Image Settings Automatic gain, exposure area, backlight compensation, white balance,
electronic shutter, 180° image rotation, electronic PTZ via AOI (API),
text overlay, privacy masks, motion detection
Resolutions From 64 x 40 to 640 x 480 (free scaling),
4:3, 16:9
Multiple Areas of Interest (AOIs)
From 64 x 40 to 1024 x 768 (free
scaling), 4:3, 16:9
Multiple Areas of Interest (AOIs)
Video Compression Motion JPEG: Multiple compression Levels
MPEG-4: SP (Level 3), ASP (Level 5)
H.264 (MPEG-4 AVC): Baseline (Level 3)
Video Streaming Simultaneous dual encoding for MJPEG and MPEG-4 or H.264
Multi streaming for MJPEG
Multicast and unicast
VBR and CBR
Table 4: BIP640c and BIP-1000c Technical Specifications
