Basler DGC-2020ES User Manual

9469200995 3-3
DGC-2020ES BESTCOMSPlus®
The DGC-2020ES plugin can be activated automatically or manually. Automatic activation is achieved by
using a USB cable to establish communication between the DGC-2020ES and BESTCOMSPlus. Manual
activation is initiated by contacting Basler Electric for an activation key and entering the key into
BESTCOMSPlus. Manual activation is useful if you want to create a settings file prior to receiving your
DGC-2020ES. Refer to Manual Activation of DGC-2020ES Plugin.
Connect a USB Cable
The USB driver was copied to your PC during BESTCOMSPlus installation and is installed automatically
after powering the DGC-2020ES. USB driver installation progress is shown in the Windows taskbar area.
Windows will notify you when installation is complete.
Connect a USB cable between the PC and your DGC-2020ES. Apply operating power to the DGC-
2020ES. Wait until the boot sequence is complete.
Start BESTCOMSPlus
®
and Activate the DGC-2020ES Plugin Automatically
To start BESTCOMSPlus, click the Windows Start button, point to Programs, Basler Electric, and then
click the BESTCOMSPlus icon. During initial startup, the BESTCOMSPlus Select Language screen is
displayed (Figure 3-2
). You can choose to have this screen displayed each time BESTCOMSPlus is
started, or you can select a preferred language and this screen will be bypassed in the future. Click OK to
continue. This screen can be accessed later by selecting Tools and Select Language from the menu bar.
Figure 3-2. BESTCOMSPlus Language Selection Dialog
The BESTCOMSPlus platform window opens. Select New Connection from the Communication pull-down
menu and select DGC-2020ES. See Figure 3-3. The DGC-2020ES plugin is activated automatically after
connecting to a DGC-2020ES.

Basler DGC-2020ES Specifications

General

Brand	Basler
Model	DGC-2020ES
Category	Controller
Language	English
