Camera Link Implementation AW00118702000
14 Basler racer Camera Link
1.5.6.1 1X Tap Geometry – 8, 10, or 12 Bit Pixel Depth
Base SDR Connector, Transmitter Circuit X
Port Camera Frame
Grabber
Bit Assignments
1X - 8 Bits 1X - 10 Bits 1X - 12 Bits
Port A0 TxIn0 RxOut0 D0 Bit 0 D0 Bit 0 D0 Bit 0
Port A1 TxIn1 RxOut1 D0 Bit 1 D0 Bit 1 D0 Bit 1
Port A2 TxIn2 RxOut2 D0 Bit 2 D0 Bit 2 D0 Bit 2
Port A3 TxIn3 RxOut3 D0 Bit 3 D0 Bit 3 D0 Bit 3
Port A4 TxIn4 RxOut4 D0 Bit 4 D0 Bit 4 D0 Bit 4
Port A5 TxIn6 RxOut6 D0 Bit 5 D0 Bit 5 D0 Bit 5
Port A6 TxIn27 RxOut27 D0 Bit 6 D0 Bit 6 D0 Bit 6
Port A7 TxIn5 RxOut5 D0 Bit 7 (MSB) D0 Bit 7 D0 Bit 7
Port B0 TxIn7 RxOut7 Not Used D0 Bit 8 D0 Bit 8
Port B1 TxIn8 RxOut8 Not Used D0 Bit 9 (MSB) D0 Bit 9
Port B2 TxIn9 RxOut9 Not Used Not Used D0 Bit 10
Port B3 TxIn12 RxOut12 Not Used Not Used D0 Bit 11 (MSB)
Port B4 TxIn13 RxOut13 Not Used Not Used Not Used
Port B5 TxIn14 RxOut14 Not Used Not Used Not Used
Port B6 TxIn10 RxOut10 Not Used Not Used Not Used
Port B7 TxIn11 RxOut11 Not Used Not Used Not Used
Port C0 TxIn15 RxOut15 Not Used Not Used Not Used
Port C1 TxIn18 RxOut18 Not Used Not Used Not Used
Port C2 TxIn19 RxOut19 Not Used Not Used Not Used
Port C3 TxIn20 RxOut20 Not Used Not Used Not Used
Port C4 TxIn21 RxOut21 Not Used Not Used Not Used
Port C5 TxIn22 RxOut22 Not Used Not Used Not Used
Port C6 TxIn16 RxOut16 Not Used Not Used Not Used
Port C7 TxIn17 RxOut17 Not Used Not Used Not Used
LVAL TxIn24 RxOut24 Line Valid Line Valid Line Valid
FVAL TxIn25 RxOut25 Not Used Not Used Not Used
DVAL TxIn26 RxOut26 Data Valid Data Valid Data Valid
CL Spare TxIn23 RxOut23 As assigned by user As assigned by user As assigned by user
Strobe TxCLKIn RxCLKOut Pixel Clock Pixel Clock Pixel Clock
Table 4: Bit Assignments for 1X Tap Geometry – 8, 10, or 12 Bit Pixel Depth (Transmitter Circuit X)
