Basler racer Manual

AW00118702000 Camera Link Implementation
Basler racer Camera Link 21
1.5.6.5 1X10 Tap Geometry – 8 Bit Pixel Depth
Base SDR Connector, Transmitter Circuit X
Port Camera Frame
Grabber
Bit Assignments
1X10 - 8 Bits
Port A0 TxIn0 RxOut0 D0 Bit 0
Port A1 TxIn1 RxOut1 D0 Bit 1
Port A2 TxIn2 RxOut2 D0 Bit 2
Port A3 TxIn3 RxOut3 D0 Bit 3
Port A4 TxIn4 RxOut4 D0 Bit 4
Port A5 TxIn5 RxOut5 D0 Bit 5
Port A6 TxIn6 RxOut6 D0 Bit 6
Port A7 TxIn7 RxOut7 D0 Bit 7 (MSB)
Port B0 TxIn8 RxOut8 D1 Bit 0
Port B1 TxIn9 RxOut9 D1 Bit 1
Port B2 TxIn10 RxOut10 D1 Bit 2
Port B3 TxIn11 RxOut11 D1 Bit 3
Port B4 TxIn12 RxOut12 D1 Bit 4
Port B5 TxIn13 RxOut13 D1 Bit 5
Port B6 TxIn14 RxOut14 D1 Bit 6
Port B7 TxIn15 RxOut15 D1 Bit 7 (MSB)
Port C0 TxIn16 RxOut16 D2 Bit 0
Port C1 TxIn17 RxOut17 D2 Bit 1
Port C2 TxIn18 RxOut18 D2 Bit 2
Port C3 TxIn19 RxOut19 D2 Bit 3
Port C4 TxIn20 RxOut20 D2 Bit 4
Port C5 TxIn21 RxOut21 D2 Bit 5
Port C6 TxIn22 RxOut22 D2 Bit 6
Port C7 TxIn23 RxOut23 D2 Bit 7 (MSB)
LVAL TxIn24 RxOut24 Line Valid
FVAL TxIn25 RxOut25 Not Used
Port D0 TxIn26 RxOut26 D3 Bit 0
Port D1 TxIn27 RxOut27 D3 Bit 1
Strobe TxInCLK RxOutClk Pixel Clock
Table 11: Bit Assignments for 1X10 Tap Geometry – 8 Pixel Depth (Transmitter Circuit X)
