Basler racer Manual

Camera Link Implementation AW00118702000
22 Basler racer Camera Link
Medium/Full SDR Connector, Transmitter Circuit Y
Port Camera Frame
Grabber
Bit Assignments
1X10 - 8 Bits
Port D2 TxIn0 RxOut0 D3 Bit 2
Port D3 TxIn1 RxOut1 D3 Bit 3
Port D4 TxIn2 RxOut2 D3 Bit 4
Port D5 TxIn3 RxOut3 D3 Bit 5
Port D6 TxIn4 RxOut4 D3 Bit 6
Port D7 TxIn5 RxOut5 D3 Bit 7 (MSB)
Port E0 TxIn6 RxOut6 D4 Bit 0
Port E1 TxIn7 RxOut7 D4 Bit 1
Port E2 TxIn8 RxOut8 D4 Bit 2
PortE3 TxIn9 RxOut9 D4 Bit 3
Port E4 TxIn10 RxOut10 D4 Bit 4
Port E5 TxIn11 RxOut11 D4 Bit 5
Port E6 TxIn12 RxOut12 D4 Bit 6
Port E7 TxIn13 RxOut13 D4 Bit 7 (MSB)
Port F0 TxIn14 RxOut14 D5 Bit 0
Port F1 TxIn15 RxOut15 D5 Bit 1
Port F2 TxIn16 RxOut16 D5 Bit 2
Port F3 TxIn17 RxOut17 D5 Bit 3
Port F4 TxIn18 RxOut18 D5 Bit 4
Port F5 TxIn19 RxOut19 D5 Bit 5
Port F6 TxIn20 RxOut20 D5 Bit 6
Port F7 TxIn21 RxOut21 D5 Bit 7 (MSB)
Port G0 TxIn22 RxOut22 D6 Bit 0
Port G1 TxIn23 RxOut23 D6 Bit 1
Port G2 TxIn24 RxOut24 D6 Bit 2
Port G3 TxIn25 RxOut25 D6 Bit 3
Port G4 TxIn26 RxOut26 D6 Bit 4
LVAL TxIn27 RxOut27 Line Valid
Strobe TxInCLK RxOutClk Pixel Clock
Table 12: Bit Assignments for 1X10 Tap Geometry – 8 Pixel Depth (Transmitter Circuit Y)
