Basler racer Manual

AW00118702000 Camera Link Implementation
Basler racer Camera Link 23
Medium/Full SDR Connector, Transmitter Circuit Z
Port Camera Frame
Grabber
Bit Assignments
1X10 - 8 Bits
Port G5 TxIn0 RxOut0 D6 Bit 5
Port G6 TxIn1 RxOut1 D6 Bit 6
Port G7 TxIn2 RxOut2 D6 Bit 7 (MSB)
Port H0 TxIn3 RxOut3 D7 Bit 0
Port H1 TxIn4 RxOut4 D7 Bit 1
Port H2 TxIn5 RxOut5 D7 Bit 2
Port H3 TxIn6 RxOut6 D7 Bit 3
Port H4 TxIn7 RxOut7 D7 Bit 4
Port H5 TxIn8 RxOut8 D7 Bit 5
Port H6 TxIn9 RxOut9 D7 Bit 6
Port H7 TxIn10 RxOut10 D7 Bit 7 (MSB)
Port I0 TxIn11 RxOut11 D8 Bit 0
Port I1 TxIn12 RxOut12 D8 Bit 1
Port I2 TxIn13 RxOut13 D8 Bit 2
Port I3 TxIn14 RxOut14 D8 Bit 3
Port I4 TxIn15 RxOut15 D8 Bit 4
Port I5 TxIn16 RxOut16 D8 Bit 5
Port I6 TxIn17 RxOut17 D8 Bit 6
Port I7 TxIn18 RxOut18 D8 Bit 7 (MSB)
Port J0 TxIn19 RxOut19 D9 Bit 0
Port J1 TxIn20 RxOut20 D9 Bit 1
Port J2 TxIn21 RxOut21 D9 Bit 2
Port J3 TxIn22 RxOut22 D9 Bit 3
Port J4 TxIn23 RxOut23 D9 Bit 4
Port J5 TxIn24 RxOut24 D9 Bit 5
Port J6 TxIn25 RxOut25 D9 Bit 6
Port J7 TxIn26 RxOut26 D9 Bit 7 (MSB)
LVAL TxIn27 RxOut27 Line Valid
Strobe TxInCLK RxOutClk Pixel Clock
Table 13: Bit Assignments for 1X10 Tap Geometry – 8 Pixel Depth (Transmitter Circuit Z)
