Basler racer Manual

AW00118702000 Pixel Data Output
Basler racer Camera Link 35
Fig. 14: Timing of Pixel Data Transmission for the 1X8 Tap Configuration
Line
Valid
Line N Line N+1
C
B
Pixel
Clock
D0
Pixel Data
(10 or 8 bits)
W-15 W-719
D1
Pixel Data
(10 or 8 bits)
W-14 W-6210
Data
Valid
D2
Pixel Data
(10 or 8 bits)
W-13 W-5311
D3
Pixel Data
(10 or 8 bits)
W-12 W-4412
D4
Pixel Data
(10 or 8 bits)
W-11 W-3
5
13
D5
Pixel Data
(10 or 8 bits)
W-10 W-2614
D6
Pixel Data
(10 or 8 bits)
W-9 W-1715
D7
Pixel Data
(10 or 8 bits)
W-8 W816
*
W-15 W-719
W-14 W-6210
W-13 W-5311
W-12 W-4412
W-11 W-3
5
13
W-10 W-2614
W-9 W-1715
W-8 W816
B
A
End of
Exposure
of Line N+1
End of
Exposure
of Line N+2
* In 1X8 configuration, data valid is only available when the camera is set for an 8 bit pixel format.
TIMING DIAGRAMS ARE NOT DRAWN TO SCALE.
W = width = the last pixel according to the current image AOI (e.g., the 2048th pixel of the image AOI
when the image AOI width is set to 2048).
