WPT, KTS, KPS,
KTM, WSM
WPT, KTS, KPS, KTM, WSM
Litograa Reverberi - Pr
Rev. 03 del 03.02.2017
IT
GB
MANUALE ISTRUZIONI
PER L’USO E LA MANUTENZIONE
INSTRUCTION MANUAL FOR
USE AND MAINTENANCE
NOTICE D’EMPLOI
ET D’ENTRETIEN
GEBRAUCHS-UND
WARTUNGSANLEITUNGEN
HANDLEIDING VOOR HET
GEBRUIK EN HET ONDERHOUD
FR
DE
NL
Rotary vanes
vacuum pump
Centrifugal pump
Rotary postive displacement
lobes pump
Rotary postive displacement
lobes pump
Rotary lobes
vacuum pump
Via Cav. Enzo Ferrari, 2
43058 Ramoscello di Sorbolo (PR) - Italy
Ph. +39 0521 663203
Fax +39 0521 663206
www.bapag.it
info@bapag.it

Table of Contents

Questions and Answers

  • H
    Heather ColonAug 14, 2025
    Why is my battioni Pagani KPS 490 overheating?
    • A
      amy96Aug 14, 2025
      Overheating in your battioni Pagani Water Pump can occur due to several reasons. It could be caused by excessive pressure, which requires you to reduce the pressure. Other causes include excessive revs rate (reduce the revs rate), a dirty cartridge filter (follow the cleaning procedure), excessive operating time (reduce operating time), blades that are too long (trim blades to the correct size), insufficient lubrication (check oil level in tank, the oil pump correct functioning, the oil cock regulation), or an insufficient cooling system (adjust the cooling system).
  • S
    Sara RichardsAug 17, 2025
    What to do if my battioni Pagani Water Pump has little vacuum or pressure?
    • S
      samuel47Aug 17, 2025
      If your battioni Pagani Water Pump is showing little vacuum or pressure, several factors could be the cause. The blades might be worn (replace blades), or some blades might be jammed in the rotor (disassemble the Rotary blades vacuum pump, clean and wash the rotor, blades, body). Other potential causes include air infiltration or leakage from the system (eliminate infiltrations), an undulated cylinder (smooth or replace the body), a dirty cartridge filter (follow the cleaning procedure), a misplaced reversing gear (remove reversing gear and position it correctly), or the crash protection system being enabled (lift the flanges and tighten the flange screws with 55 Nm).
  • E
    Emily ChenAug 25, 2025
    How to fix a battioni Pagani Water Pump that is beating against the external surface?
    • H
      Hannah PinedaAug 25, 2025
      If your battioni Pagani Water Pump is beating against an external surface, it might be because the revs rate is too low (increase revs rate) or the lubricating oil quantity is too high/low and not appropriate (clean Rotary blades vacuum pump and replace oil).
  • R
    Rebekah HendrixAug 27, 2025
    Why is there no lubricating oil circulation in my automatic lubrication battioni Pagani KPS 490 Water Pump?
    • C
      Chelsea JohnsonAug 27, 2025
      If there's no lubricating oil circulation in your automatic lubrication battioni Pagani Water Pump, it could be due to a few reasons. There might be air intake at pipe fittings (replace pipe fittings), the lubrication tube might be badly inserted in pipe fittings (insert lubrication tube correctly), or the oil pump chamber might contain air (full the pump chamber with oil).
  • C
    Chelsea PenningtonAug 31, 2025
    What causes smoke to come out of the discharge tube of a battioni Pagani KPS 490 and how to solve it?
    • D
      Daniel HowardAug 31, 2025
      If smoke is coming out of the discharge tube of your battioni Pagani Water Pump, it's likely due to excessive lubrication. Adjust the lubrication to resolve this issue.
  • P
    pthomasSep 3, 2025
    What causes a battioni Pagani KPS 490 power take-off not to rotate?
    • S
      stonemeghanSep 3, 2025
      If the power take-off of your battioni Pagani Water Pump does not rotate, it could be due to a broken blade (replace blades and check if rotor pin is bent) or a foreign body has entered the Rotary blades vacuum pump (remove foreign body).
  • N
    nhenrySep 6, 2025
    What causes water to leak from the blanking caps or fittings of a battioni Pagani Water Pump?
    • B
      bushkristySep 6, 2025
      If water leaks from the blanking caps or fittings of your battioni Pagani Water Pump, it is likely due to insufficient tightening. Tighten until there is no more leakage.
  • J
    Jacob ThomasSep 9, 2025
    What to do if the sewage output from the discharge curve of my battioni Pagani Water Pump?
    • J
      Jennifer ClementsSep 10, 2025
      If the sewage output is deviating from the discharge curve in your battioni Pagani Water Pump, it could be due to malfunctioning valves. Check the valves to ensure they are working correctly.
  • S
    Scott CollierNov 19, 2025
    Why does my battioni Pagani KPS 490 have no suction or no compression?
    • A
      Alex WilsonNov 19, 2025
      If your battioni Pagani Water Pump has no suction or compression, it could be due to several reasons: * The handle is badly positioned (position the handle correctly). * The reversing gear is badly positioned (position the reversing gear correctly). * The rotary blades pump runs backwards (reverse direction of rotation). * All blades are jammed (disassemble the pump, clean and wash blades, rotor and body). * Blades protrude from rotor slots anomalously (disassemble the pump, clean and wash blades, rotor and body). * The rubber ball closes the overflow valve (increase passage of air inside valve). * [KPS] The plate is locked (unscrew the cap or vacuum adjustment valve where present placed on the filter cover and move the plate downward until releasing or unlocking it). * P...

Summary

Introduction to Pump Operation

Operator Safety Instructions

Important safety instructions for operator safety and compliance with risks.

Safety and Usage Guidelines

Obligatory Safety Signs

Mandatory safety signs to be displayed in the workplace and around the vacuum pump.

Conditions and Limits of Use

Usage requirements and potential hazards for the vacuum pump.

Assembly, Fitting, and Installation Procedures

Assembly and Mounting

Detailed procedure for assembling and mounting the vacuum pump.

Uninstallation Procedures

Uninstallation Steps by Version

Detailed procedures for uninstalling pumps based on their specific versions.

Disassembly and Re-fitting

Back Part Disassembly

Step-by-step instructions for disassembling the pump's back section.

Front Part Disassembly

Step-by-step instructions for disassembling the pump's front section.

Front Part Re-fitting

Procedure for refitting the front part of the vacuum pump.

Operation and Controls

Pump Operation Parameters

Key operating parameters and safety warnings for the vacuum pump.

Troubleshooting Guide

Low Vacuum or Pressure Issues

Troubleshooting common problems related to insufficient vacuum or pressure.

Overheating and Leakage Issues

Diagnosing and resolving pump overheating and water leakage problems.

Rotation and Suction;Compression Issues

Addressing problems with pump rotation, suction, and compression.

Maintenance and Technical Assistance

Blade Inspection and Replacement

Procedures for inspecting and replacing the pump blades.

battioni Pagani KPS 490 Specifications

General IconGeneral
Brandbattioni Pagani
ModelKPS 490
CategoryWater Pump
LanguageEnglish
