EN-31
OPERATION INSTRUCTIONS
WARNING!
Read all instructions carefully. Do not connect the spark
plug before it is completely assembled. Always use gloves during assembly.
INTENED USE
1. This 4 in 1 petrol multi-tool is designated with an engine displacement of 30cc.
Depending on the attached accessory this product is intended to be used as:
a). Brush Cutter: With the cutter blade attached the product is intended to cut heavier
weeds, brush and similar vegetation.
b). Grass trimmer: With the line spool attached the product is intended to cut smaller types
of weed, lawn grass or similar soft vegetation. It must not be used to work on unusually
thick, dry or wet grass, e.g. pasture grass, or to shred leaves.
c). Pole hedge trimmer: With the hedge trimmer blade attached the product is intended for
trimming wide and high hedges, bushes and shrubs.
d). Chain saw: With the saw chain/guide bar assembly attached the product is intended
for cutting limbs. The product may only be used with the guide bar/saw chain combination
stated in these instructions. It is not permitted to use other types or sizes.
2. The product must not be used for cutting other materials, such as plastic, stone, metal
or wood that contains foreign objects and must not be used outside of domestic premises.
3. Observe the technical data for the maximum cutting capacity according to the application
(see “Technical Date”). Do not cut plants exceeding the stated maximum capacity.
BEFORE OPERATION
Cutting or Trimming Guard Assembly (See Fig. A1-A3)
1. Remove the pre-assembly screw on the safety guard.
2. Align the screw location hole, and then insert the safety guard into the tube.
3. Tighten the screw using screwdriver
Grass Trimmer Assembly and Disassembly (See Fig. B1-B2)
1. Make sure that the cutting / trimming guard have been attached properly.
2.Screw the nut clockwise and move ange (31)and nut (32).
3. Rotate the backing ange until its hole is aligned with the notch in the gear head.
4. Insert the spindle lock rod into the hole to lock the spindle.
5. Screw the trimmer head on the spindle anti-clockwise.
6. Reverse the above order of steps to disassemble the grass trimmer.
