5. Encoder operating parameters
Description of operating parameters
Parameter
Significance
Sense of rotation
Behaviour of the output code depending on the sense of rotation of the shaft seen
looking at the flange
CW = Increasing values with clockwise rotation
CCW = Increasing values with counterclockwise rotation
Resolution
Number of steps per revolution, input in integral steps
Measurement range
Total resolution = number of steps per revolution x number of revolutions,
input in integral steps
Preset value
A certain output value is assigned to the current position value (referencing)
Operating parameter values
Parameter
Value range
Default setting
Data type
Sense of rotation
CW/CCW
CW
Octet string
Resolution
1 to 4096 – magtivo
1 to 8192 – multivo
1 to 262144 – activo/multivoPlus
4096
8192
262144
Unsigned 32
Measurement range
1 to 67108864 (2
26
) – magtivo
1 to 536870912 (2
29
) – multivo
1 to 2147483648 (2
31
)
– activo/multivoPlus
67108864
536870912
2147483648
Unsigned 32
Preset value
0 to (measurement range - 1 step)
0
Unsigned 32
