Baumer PA408 - Page 15

Baumer Operating functions | 6
V1 | PA408 Operating Manual 15
Input temperature
Select temperature sensor with button r.
Pt100
Pt1000
Thermocouple J, K, T, N
Confirm with .
Pt100/Pt1000
Select the required unit/resolution with button .
Degrees Celsius
Resolution in 1/10 degrees Celsius
Degrees Fahrenheit
Resolution in 1/10 degrees Fahrenheit
Confirm with .
Proceed with configuration of display offset.
Programmable from -9.9 to +99 units depending on resolution.
The offset value can serve to compensate for any difference between actual
value and measured value.
Confirm with .
Thermocouple
Select thermocouple with button .
Thermocouple J
Thermocouple K
Thermocouple T
Thermocouple N
Confirm with .
Select the required unit/resolution with button .
Degrees Celsius
Resolution in 1/10 degrees Celsius
Degrees Fahrenheit
Resolution in 1/10 degrees Fahrenheit
Confirm with .
