6 | Operating functions Baumer
20 Operating Manual PA408 | V1
Select the input signal value with button .
Limit 1
Limit 2
Confirm with .
Select the input signal value with button .
HIGH = Enabled at display value ≥ limit
LOW = Enabled at display value ≤ limit
Confirm with .
Value programmable from -9999 to 9999.
Relay output in idle state
Select the input signal value with button .
Normally open
Normally closed
Confirm with .
Function of the relay output
Time delay
Hysteresis
Delay or hysteresis value
Programming the delay (dLY) from 0 to 99 s or hysteresis (HYS) from 0 to
9999 display units.
Configuration is in an analog way to [Set1].
