Baumuller DST2 Series - Control Port: ECN 1313; EQN 1325

TAM 00695 24
DST2-135 – 400 W 10 / 2019
Three-phase synchronous motor, water-cooled English
7.4 Control port: ECN 1313 / EQN 1325
(encoder with EnDat 2.1-port from Heidenhain companies
Pin
Signal
8
10
9
2
5
7
6
1
11
13
16
17
12
14
15
3
4
View to contact side
of female connector
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
U
p
0 V
U
p
Clock
Clock inv.
0 V
B+
B-
Data
A+
A-
Data inv.
Figure 5: Pool assignment ECN 1313 / EQN 1325
Note:
 For other encoder types and optional lead for the temperature sensor via the encoder
cable, see the enclosed wiring diagram or technical documentation for the pin assignment
 The encoder from Section 7.2 to 7.4 are components susceptible to ESD.
