TAM 00695 8
DST2-135 – 400 W 10 / 2019
Three-phase synchronous motor, water-cooled English
2.4 Technical Data
The technical data you can find in the technical product list DST2-135 - 400 W- or online at:
www.baumueller.com under Download and Technical documentation. If necessary, you can
request the corresponding documentation
Storage Class 1K2/1M1 according to DIN EN 60721-3-1:1995
Transport Class 2K2/2M1 according to DIN EN 60721-3-2:1995
Note:
To avoid frost damage, cooling water should be removed at ambient temperatures < 3 °C!
Bearing Rolling bearings with permanent grease lubrication
(optional: re-lubrication)
Thrust-bearing Axial spherical roller bearing with oil lubrication
Calculated bearing life Lh 10 = 20000 h (guideline value)
Caution!
If the electric motor supplied is not a standard type according to the technical list or if special
contractual arrangements have been made, there may be differences in the information
contained in these Commissioning and Maintenance Instructions. If this is so, request the
relevant technical supplements.
2.5 Transport, intermediate storage
Water-cooled motors:
To avoid frost damage it must be ensured that there is no coolant in the motor during
the transport or intermediate storage at ambient temperatures < 3 °C.
Transport:
The permitted environmental conditions which affect the motor during the transport
must be taken from DIN EN 60721-3-2 (class 2K2/2M1). Contrary to the DIN, a
reduced temperature range of – 15 °C to + 60 °C is permitted.
Suitable load lifting tackle must be used, e. g. belt webbing and loop belts. If provided,
the lifting lugs of the motor can be used for lifting.
The terminal boxes and motor connectors must not be used for securing the motor for
transport or as lifting eyes.
The regulations of the respective countries must be adhered to during transport. Lifting
devices and transport and lifting tackle must comply with the relevant regulations.
Series “DST2-..VA..” electric motors have the following weights in the overall length classes:
approx.100 kg to
approx.185 kg
approx. 200 kg to
approx. 470 kg
approx. 370 kg to
approx. 860 kg
approx. 450 kg to
approx. 1,250 kg
approx. 2100 kg to
approx. 3600 kg
Table 1: Weights of DST2-.. VA-motors
