Bavaria VIRTESS 420 - Fuse and AC Module Locations (Main Deck); Fuse and AC Module Locations (Lower Deck)

Systems(someoptional)
33
7.6.2. Positions of the conventional fuses and AC module boxes main deck
7.6.3.
7 887
Positions of the conventional fuses and AC module boxes lower deck
5 2
6 15 3 4
7.6.4. Allocation and denotation of installation positions
Pos Position of fuses
1 Aftcabinport,behindmirror(onlyconventionalfuses)
2 Aftcabinstbd(ModulesB3andB4)
3 Owner‘scabinPortside(B1)
4 Owner‘s cabin below berth
5 Engine room
6 AC modules AC1 and AC2
7 AC module AC3
8 Battery disconnect switches engine and consumers
