Bavaria VIRTESS 420 - Drawing Gas System Fly Deck (General View)

Systems(someoptional)
45
7.12.1. Detail view galley
K
B
A
C
D
E
F
G
H
L
K
7.12.2. Notation of the main decks gas system components
Pos. Description
A Gascylinder(bottle)withGOK-Lowpressureregulator(GasboxunderthestepsleadingtotheFly
deck)hLPG30mbar
B Gasbox,drained
C Angledxturestainlesssteelatbulkhead
D Gasdistributorblocktwovalves(inlocker)
E Angledxtureatbulkhead
F Angledxtureatbulkhead/Adapterstraight
G Gascooktop(Option)/Gasoven(Option)
H Rubberhose(Gasbox)6bar
K Angledxtureatbulkhead
L Copper pipe 8 mm
7.13. Drawinggassystemydeck(generalview)
