Baxtran BR16 User Manual

ENUSER’S MANUAL BR16
52
7 PIN CELL SCHEME
6
2
5
4
7
1
3
6
7
CÉLULA
DE
CARGA
PIN 1 EXC +
PIN 2 SEN+
PIN 3 SIG +
PIN 4 SIG -
PIN 5 SEN -
PIN 6 EXC -
PIN 7 GND
CONNECTION RS232
5
4 3 2 1
9
8 7
6
2 Tx
3 Rx
5 GND
PROTOCOL
UARTsignalofEIA-RS232C
SIGNALUARTEIA-RS232C
Serialoutput 1200 / 2400 / 4800 / 9600 / 19200 / 34800 bps
Data Bits 8 bits
Paritybits No
STOPBITS 1 bit
HEADINFORMATION
HEAD1(2BYTES) HEAD2(2BYTES)
OL–Extracharge
ST–Stable NT–Netweight
US–Unstable GS–Netweight
