ENUSER’S MANUAL BR16

1. SPECIFICATIONS

BR16

Precision Clase III

Load Cell Sensitivity Range 1.5 ~ 3.0mV/V

Nonlinearity ≤0.01%F.S

Voltage cell DC 5V

Step 1/2/5 (selectable)

Frequency of sampling 20timespersecond(outsidemeteorology)

Internal resolution 300.000~600.000

2. EXCITATION

BR16

Input 230~240V

Output 10V 600mA

Rechargeable Battery 6V/4Ah

3. BEFORE ITS USE

1. Use an independent electric source to prevent electronic disturbances.

2.Don’tplaceanyobjectontheplatformwhenswitchingontheindicator.

3.Please,warm-upthescaleduring2-3minutesbeforeusingit.

4. Avoid sudden changes in temperature and draughts.

5.Don’toverloadthescale;donotexceeditsmaximumcapacity.

4. CONSUMPTION

▪ Normalconsumptionatrest:approx.12mA-333h

▪ Consumptionwithbacklight:aprox.36mA-111,11h

▪ ConsumptionwithbacklightandoutputRS-232:aprox.48mA-83h

▪ Batteryduration:withoutbacklight,aprox.320h

5. LOAD CELL CONNECTION TO THE INDICATOR

1)Theconnectoroftheloadcellis7pins.

2)Whentheindicatorisworking,donotremovetheconnectorfromtheloadcell,thisactcoulddamagetheequipment.
