Bay-Tek Spin-N-Win! - Page 11

11
SET UP GUIDE
Plug in cables CE6921, CE6938 and CE6942
(that were ran up from the playeld) into their
corresponding match that are fed out the back of
the marquee.
Route excess cables back down into the hole on
the back of the playeld. If desired, use the wire
loom located inside the cash box and wrap around
the cables to cover and protect them.
Close the back door on the playeld, ONLY LOCK
THE BOTTOM LOCK!
