Bay-Tek Spin-N-Win! - Mainboard Pinout Guide

30
MAINBOARD PINOUT GUIDE
Pin Type Pur
p
ose Ref Pin #
LOWSIDE #1,w diode J22 1
LOWSIDE #2, w diode J22 2
LOWSIDE #3 J22 3
LOWSIDE #4 J22 4
LOWSIDE #5 J22 5
LOWSIDE #6 J22 6
LOWSIDE #7 J22 7 Pin Type Purpose
Ref Pin #
LOWSIDE #8 J22 8 Ground J24 1
LOWSIDE #9 J22 9 Ground J24 2
+12 Volts J22 11 +12 Volts J24 3
+12 Volts J22 12 +12 Volts J24 4
+12 Volts J22 13 PB7 J24 5
+12 Volts J22 14 LOWSIDE #12 J24 6
+12 Volts J22 15 PX29 J24 7
+12 Volts J22 16 HIGHSIDE #10 J24 8
HIGHSIDE #11 J24 9
3.3V J24 10
PX37 Ticket Notch #1 J5 1
Ground Ground for Ticket Dis
p
enser J5 2
HIGHSIDE #13 Games Counter J25 1 PB18 Ticket Motor #1 J5 3
HIGHSIDE #14 Tickets Counter J25 2 +12 Volts Power for Ticket Dis
p
enser J5 4
PX10 Menu Button 1 J25 3
PX11 Menu Button 2 J25 4 PB16 Ticket Notch #2 J9 1
Ground J25 5 Ground Ground for Ticket Dispenser J9 2
Ground J25 6 PB17 Ticket Motor #2 J9 3
+12 Volts Power for Ticket Dis
p
enser J9 4
+12 Volts Coin Door Power J6 1
PA05 Coin Input J6 2 PA06 DBA Input J8 1
Ground Coin Ground J6 3 +12 Volts J8 2
Ground J8 3
Ground J8 4
= LED Constant Current Drive
= 12 Volts
= Ground
BayTek NEWGEN1 Hardware REV G & up
=Low Side Driver
=High Side Driver
= TTL Input/Output
PB19 Start Handle Up Position J21 1 +12 Volts J29 1
PX39 Start Handle Down Position J21 2 +12 Volts J29 2
PX00 J21 3 +12 Volts J29 3
PX01 Low Ticket Switch #1 Input J21 4 PA21 R0a J29 4
PB20 Low Ticket Switch #2 Input J21 5 PA23 B0a J29 5
PX02 J21 6 PA22 G0a J29 6
PB21 J21 7 PA25 G1a J29 7
PB22 J21 8 PA24 R1a J29 8
PB23 J21 9 PA27 A address J29 9
PB24 J21 10 PA26 B1a J29 10
Ground J21 11 PC0 C address J29 11
Ground J21 12 PA28 B address J29 12
Ground J21 13 PX20 CLKa J29 13
Ground J21 14 PC1 D address J29 14
+12 Volts J21 15 PX21 B1b-LED DATA J29 15
+12 Volts J21 16 PB0 Display OutputEnable J29 16
+12 Volts J21 17 PX22 G1b-LED LATCH J29 17
+12 Volts J21 18 PB1 Display LATCH J29 18
PB25 J21 19 PX24 B0b-LED ADR1 J29 19
PB26 NJ Lockout J21 20 PX23 R1b-LED ADR0 J29 20
PX26 R0b-LED ADR3 J29 21
PX25 G0b-LED ADR2 J29 22
PX28 J29 23
Ground J29 24
Ground J29 25
Ground J29 26
