User’s Manual
33
1.7.2 COM1 RI/+5V/+12V Selection (JCOMPWR1)
+5V (Default)
+12V
Ring
1.7.3 COM2 RI/+5V/+12V Selection (JCOMPWR2)
+5V (Default)
+12V
Ring
