36
No Label Function Description
9 USB34 USB 2.0 connector These two 4-pin Universal Serial Bus (USB)
ports are available for connecting USB 2.0
devices.
10 VGA_DVI VGA port This 15-pin port is for a VGA monitor or other
VGA-compatible devices.
11 COM12 Serial port connector D-Sub 9-pin, male
12 KBMS PS/2 KB connector This port is for a PS/2 keyboard
