BCM MX945GME - Audio Amplifier Connector: JAMP1; Front Audio Connector: JAUD1

Hardware
Setup
Audio Amplifier Connector: JAMP1
The JAMP1 is used to connect audio amplifiers to enhance audio performance.
Pin Definition
JAMP1
1
PIN
1
2
3
4
SIGNAL
A
MP_L-
A
MP_L+
A
MP_R-
A
MP_R+
Front Audio Connector: JAUD1
The JAUD1 connects to an optional audio bracket that provides extra front panel
audio IO jacks.
2
1
14
13
JAUD1
Audio Bracket
(Optional)
JAUD1 Pin Definition
PIN
1
3
5
7
9
1 1
13
SIGNAL
5V_SB
SPDF0
GND
LEF_OUT
CEN_OUT
A
UD_GPIO21
SIDE_L
PIN
2
4
6
8
10
12
14
SIGNAL
VCC3
NA
SPDF1
SURR_OUT_R
SURR_OUT_L
A
UDIO GND
SIDE_R
2-11
