BDCOM S3756F Hardware Installation Manual
- 20 -

If the console port does not work after the system is started up, check whether the
console port is set to a baud rate of 9600 bps, eight data bits, no sum check bit, one
stop bit and no traffic control.
5.2 Indicator Description
The following table shows the indicators of the BDCOM S3756F switch and their description:
No.
Abbrev.
Name
Description
1
PWR
Power indicator
When the switch is powered on,
the indicator is on.
2
SYS
System indicator
When the indicator is always on,
the system is being started up.
When the indicator flickers, the
system works well.
3
LINKACT
Upper indicator for
each port
When the indicator is always on,
the port is linked.
When the indicator is off, the link is
not linked.
