Personal protective equipment
Wear the following protective equipment at
all times when operating the machine:
Symbol Meaning
Close-tting work protection
clothing with a low tear strength
Goggles for protecting eyes
against ying parts and liquids
and ear protection in areas with
noise emission >80 dB(A)
Safety shoes for protecting feet
against falling objects.
Also wear the following protective equipment
during special work:
Symbol Meaning
Helmet for protecting your head
against falling objects
Wear a harness where there is a
danger of falling.
Gloves for protection against
injuries
Components / delivery contents
Machine overview
1 Core drill
(not supplied as standard)
2 Tool mounting
3 Gearbox
(with selector lever:
2-stage for MABasic400 and 450
4-stage for MABasic 850)
4 Drive motor
5 Handle
6 Hand lever
7 Operating panel
8 Magnetic foot
9 Machine slide and guide
12 Filler neck for cutting oil
13 Cutting oil tank
Operating panel
10 Motor ON/OFF switch
11 Magnet ON/OFF switch
Delivery contents
20 Core drilling machine
21 Safety lashing strap
22 ZAK075 ejector pin
23 Transport case
24 Hexagonal offset screwdriver
SW 4 for MABasic 200/400
SW5 for MABasic 450
SW5 + SW6 for MABasic 850
25 Industrial holder
(ZIA219KN for MABasic 450
ZIA319KN and
ZIA32KN for MABasic 850)
Operating instructions/guarantee card
(not illustrated)
