Use
Select the rotating speed range
(only MABasic 400, 450 and 850)
ATTENTION
► Switch the gear stages only with the
machine at standstill.
NOTE
► Select the speed range according to
the material and drilling diameter.
Select the gear MABasic 400/450
The machine has a gearbox with two me
-
chanical gear stages. The rotation speeds of
the gear stages are specied in the technical
data.
To select the desired gear stage, set se
-
lector lever on the gearbox (3) to stage
1 or 2 with the machine switched off.
Select the gear MABasic 850
The machine has a gearbox with four me
-
chanical gear stages. The rotation speeds of
the gear stages are specied in the technical
data.
To select the desired gear stage, switch
the machine off and set both selector
levers on the gearbox (5) to the desired
stage as shown in the table below.
Gear stage
Selector lever
anti-clock
-
wise
clockwise
Stage 1
▼ ▲
Stage 2
▼ ▼
Stage 3
▲ ▲
Stage 4
▲ ▼
Activating/deactivating
the magnetic clamp
Activating the magnetic clamp
ATTENTION
► To prevent the magnet from overheat
-
ing, switch on the magnetic clamp only
when the machine is standing on a
magnetic substrate.
Turn on the switch (11). The indicator
lamp in the switch (11) lights up.
ATTENTION
► The maximum magnetic clamp
-
ing force is only available after
switching on the motor.
Deactivating the magnetic clamp
Hold the handle tightly (5) to stop the
machine from slipping.
Turn off the switch (11). The indicator
lamp in the switch (11) extinguishes.
Switching the machine ON/OFF
Using the ON/OFF switch (10), turn the
machine ON with the green button (I)
and OFF with the red button (O).
NOTE
► The machine can only be switched on
when the magnetic clamp has been
switched on.
► Allow a severely overheated machine
to run on at idle speed for approx. 2
minutes to cool it down.
► The machine switches off automatically
in the event of a power failure or if the
magnetic clamp is switched off.
