TROUBLESHOOTING
Br3-X will not react
to any inputs
Incorrect power Verify power supply of 12 to 24
VAC/VDC +/-10% is wired to
correct terminals
Not programmed Ensure a function is programmed,
Br3-X does not show 00, and all 'h'
values are set to at least 01
Incorrect wiring Verify wiring is applied exactly as
described for specific function
programmed
Defective Br3-X Replace Br3-X
Br3-X has no output Incorrect output devices Ensure proper devices are
connected to outputs for the
specific function programmed
Not programmed Ensure a function is programmed,
Br3-X does not show 00, and all 'h'
values are set to at least 01
Incorrect wiring Verify wiring is applied exactly as
described for specific function
programmed
Incorrect jumper settings Ensure all jumpers are configured
correctly for specific application
Defective Br3-X Replace Br3-X
Br3-X output is con-
stant/maintained
One or more of IN-1
through IN-4 have shorted
Resolve respective short
E1, E2, E3, E4, E5 EEPROM error Reset Br3-X and reprogram
BR3 FUNCTION BR3-X FUNCTION
21 22
25
28, 29, 36, or 37
35
36 or 37
75
28, 29, 36, or 37
FUNCTION CROSS REFERENCE
TEST
Upon completion of jumper settings, wiring, and programming, test the Br3-X to ensure all function parameters are
working correctly and as intended for the specific application.
STATUS DESCRIPTION
r1
relay 1 closed when wired NO or open when wired NC
r2
relay 2 closed when wired NO or open when wired NC
r3
relay 3 closed when wired NO or open when wired NC
r-
relay 1 and relay 2 closed when wired NO or open when wired NC
r-
relay 1 and relay 3 closed when wired NO or open when wired NC
r-
relay 1, relay 2, and relay 3 closed when wired NO or open when wired NC
RELAY STATUS
