FUNCTIONS
FUNCTION DESCRIPTION LOGIC
10
timer
• activation of relay 1 via trigger of input 1
• reverse logic available
11
ratchet / latching • ratchet/latching of relay 1 via trigger of input 1
22
2-relay sequencer
+ inhibitor
• sequence of relay 1 and relay 2 with inhibiting of input 1 until input 2, input 3, or
WET input is triggered
• activation of input 4 reinhibits input 1
28
2-relay sequencer
+ door position
• sequence of relay 1 and relay 2 via trigger of input 1 or WET input
• input 2 allows delay to run when open but not when closed
29
deactivation timer
• sequence of relay 1 and relay 2 via trigger of input 1 or WET input
• input 2, once opened after sequence, allows relay 1 to deactivate
• input 2 allows delay to run when open but not when closed
• input 3 disables sequence, reverse logic available
36
3-relay sequencer
+ ‘1-shot’
• sequence of relay 1 and relay 2 and relay 3 via trigger of input 1 or WET input
• relay 1, relay 2, and relay 3 can be maintained or '1-shot'
37
3-relay sequence with
‘independent relay’
• sequence of relay 1 and relay 2 and relay 3 via trigger of input 1 or WET input
• relay 1, relay 2, and relay 3 can be 'independent' or sequenced
50
interlock timer • interlock of relay 1 and relay 2 via trigger of input 1 and input 2, respectively
55
interlock ratchet /
latching
• interlock ratchet of relay 1 and relay 2 via trigger of input 1 and input 2, respectively
65
2-way 2-relay
sequence
• sequence of relay 1 and relay 2 via trigger of input 1
• sequence of relay 2 and relay 1 via trigger of input 2
• input 3 triggers relay 1 individually, input 4 triggers relay 2 individually
NL
normally locked
restroom
• sequence of relay 1 (lock), relay 2 (door), and relay 3 (occupied indicators) for normally
locked, single occupancy restrooms
NU
normally unlocked
restroom
• sequence of relay 1 (lock), relay 2 (door), and relay 3 (occupied indicators) for normally
unlocked, single occupancy restrooms
DN
3-relay sequencer +
'day / night mode'
• sequence of relay 1 and relay 2 and relay 3 via trigger of input 1 or WET input
• input 2 operation dependent upon input 4 ('day / night mode')
00
disable
• Br3-X disabled
• 00 is the default setting and has no assigned function
WIRING
Each Br3-X function is wired differently. Please review and follow the appropriate wiring diagram shown for each function.
PARAMETERS
PARAMETER DESCRIPTION LOGIC
h1
relay 1 hold time
00 - 60 seconds
countdown begins AFTER release of input 1 or WET input
h2
relay 2 hold time
00 - 60 seconds
countdown begins AFTER d1 (delay between relay 1 & relay 2) expires
h3
relay 3 hold time
00 - 60 seconds
countdown begins AFTER d2 (delay between relay 1 & relay 3) expires
d1
delay between
relay 1 & relay 2
00 - 60, _1 (1/4), _2 (1/2), _3 (3/4) seconds
delay begins AT activation of input 1 or WET input
d2
delay between
relay 1 & relay 3
00 - 60, _1 (1/4), _2 (1/2), _3 (3/4) seconds
delay begins AT activation of input 1 or WET input
rL
reverse logic
00 = normal logic
input 1 trigger must be NO and close
its contact to trigger
01 = reverse logic
input 1 trigger must be NC and open
its contact to trigger
nP
no parameters no parameters available for selected function
