Operation
The green LED serves as a control for the 24 V supply voltage.
The red LED indicates impermissibly high generator operation.
If the tubular drive is powered at over double the rated
speed, the voltage will increase to over 50 V, which will be
indicated by the red LED. This operating situation must be
avoided by means of design-based measures.
As the load on the tubular drive increases, the transformer voltage and the duty cycle
decrease.
Transformer voltage (V)
Motor current (A)
Maintenance
This control unit is maintenance-free.
Cleaning
Only clean the outside of the housing with a suitable cloth. Do not use cleaning agents,
as these may damage the plastic.
Disposal
This product is made of various materials which must be disposed of properly. Find out
about the applicable regulations on recycling or disposal for this product in your coun-
try.
The packaging material must be disposed of properly.
